Strength test stand PFA 0/2-600

The strength test stand PFA0/2-600 has been designed for testing tap fittings to be connected to gas and water pipes up to nominal diameter 600. Appropriate settings on the system facilitate the testing of various geometrical shapes and nominal sizes.

The system consists of two separate clamping stations, which are equipped with a stable and reliable protective hood. The test medium is air of adjustable test pressures. The test parameters input is realised in a customer-specific manner from permanently programmed values via manually changeable ones up to the type-specific test database. The test results are also evaluated customer-specifically, from simple signalling of the test result via signing to a database of the test results with automatic certificate generation.

Technical data

Testable range: ferrules up to nominal diameter 600

Test method: BA in accordance with DIN 3230 Part 3 with evaluation according to the pressure drop method

Test duration: ca. 1 min.

Utilities connections:
  • Elt: 230V/10A/50Hz
  • Compressed air: 7-10 bar
Dimensions:
Length: 1000 mm
Width: 750 mm
Height: 1800 mm
